Function Key Retracts Latchbolt (ANSI 03):
Outside always locked, key retracts latch for entrance, also known as Storeroom function
Features:
UL listed panic proof exit device
Constructed of high quality materials for strength and durability
Exceeds criteria for BHMA Grade 1 certification
1/4″ Standard hex key dogging
Requires one rim cylinder (Product 12E72S2RP626, sold separately) and one mortise cylinder (Product 1E74C4RP3626, sold separately)
Requires cylinder (not included) please use above options or purchase separately
Covered by Precision’s 5 year mechanical warranty
Specifications:
Height: 8-5/16″
Width: 36″
Projection: 3-1/2″
Backset: 2-3/4″
Door Thickness: 1-3/4″
Material: Aluminum, Brass, Bronze, Stainless Steel
Additional Precision Links
Precision Apex 2300 Collection
Dimensions and Measurements
| Height | 8.315 in. |
| Width | 36 in. |
| Projection | 3.5 in. |
| Backset | 2-3/4″ |
| Door Thickness | 1-3/4″ |
Warranty and Product Information
| ADA | Yes |
| Approved for Commercial Use | Yes |
| Manufacturer Warranty | 5 Year Mechanical |
| Collection | Apex 2000 |
| Certifications | ANSI, UL |
| ANSI Certification | A156.3 |
| BHMA Certification | Grade 1 |
| Fire Rated | No |
Characteristics and Features
| Handshower | Left, Right |
| Panic Proof | Yes |
| Cylinder Type | Single Cylinder |
| Exit Trim Function | Night Latch |
| Delayed Egress | No |
| Dogging | Standard Hex Key |
| Exit Device Type | Mortise Lock Device |
| Color | Satin Aluminum |
| Color Tone | Neutrals |
