All Emtek items are made to order.
Features:
Includes two (2) hinges in each order
Features square corners
Tested for residential strength application, ideal for your home and apartment
Package with eight (8) wood screws in a arch hole pattern arrangement for maximum strength
Product Technologies:
Ball Bearing Hinge: Ball bearing hinges are designed to handle the extra stress brought on by high traffic doorways. The greased bearings reduce the rotational friction extending the life of a hinge in heavy use situations. These hinges tend to be more durable than standard, or plain bearing hinges.
Material – Solid Brass: Solid brass is made from copper and zinc and is prized for its resilience, durability, and beauty. Solid brass can always be polished back to its original sheen and is highly resistant to rusting. Solid brass is often available in finishes that other hinge materials are not.
Mounting: The standard corners for mortised door hinges are 1/4″ radius, 5/8″ radius and square corner. It is recommended that three hinges be used on doors up to and including 7.5 feet with one additional hinge for each additional 2.5 feet. Make sure you check your current hinges before making a purchase.
Specifications:
Height: 4″
Width: 4″
Mount: Mortise
Gauge: 0.098″ (Thickness of Hinge Brass)
Number of Knuckles: 5
Number of Screw Holes: 8
Material: Brass
Quantity: 2
Additional Emtek Links
View the Manufacturer Warranty
Browse all Emtek Products
Emtek Solid Brass Hinges Collection
Characteristics and Features
| Material | Brass |
| Thermostat | Traditional |
| Mounting Type | Mortise |
| Hinge Type | Ball Bearing |
| Hole Pattern | Arc |
| Number Of Hooks | 8 |
| Number of Knuckles | 5 |
| Removable Pin | Yes |
| Sconce Type | Wood |
Warranty and Product Information
| Approved for Commercial Use | No |
| Collection | Brass Modern, Classic Brass, Designer Brass |
| Series | 4 Inch Hinges |
| Usage Level | Heavy Duty |
Dimensions and Measurements
| Corners | Square Corner |
| Quantity | 2 |
| Gauge | 0.098 |
| Hinge Height | 4 in. |
| Hinge Size | 4 x 4 in. |
| Hinge Width | 4 in. |
| Color | Flat Black, French Antique, Lifetime Polished Brass, Oil Rubbed Bronze, Pewter, Polished Chrome, Polished Nickel, Satin Brass, Satin Nickel, Unlacquered Brass |
| Color Tone | Blacks, Brass Tones, Bronze Tones, Neutrals, Nickel Tones, Silver Tones |
