All Emtek items are made to order.
Emtek quality ball bearing hinges are made with the finest steel alloys featuring removable ends for the attachment of the finial of your choice. Complete your project with details that are consistent and thoughtful.
Features:
Includes two (2) hinges per order
Features square corners
Tested for heavy duty strength
Features a removable pin, allowing to easily remove a door
Packaged with six (6) wood screws
Arc hole pattern arrangement for maxuimum durability
Ball Bearing Hinge: Ball bearing hinges are designed to handle the extra stress brought on by high traffic doorways. The greased bearings reduce the rotational friction extending the life of a hinge in heavy use situations. These hinges tend to be more durable than standard, or plain bearing hinges.
Material – Solid Brass: Solid brass is made from copper and zinc and is prized for its resilience, durability, and beauty. Solid brass can always be polished back to its original sheen and is highly resistant to rusting. Solid brass is often available in finishes that other hinge materials are not.
Mounting: The standard corners for mortised door hinges are 1/4″ radius, 5/8″ radius and square corner. It is recommended that three hinges be used on doors up to and including 7.5 feet with one additional hinge for each additional 2.5 feet. Make sure you check your current hinges before making a purchase.
Specifications:
Height: 3.5″
Width: 3.5″
Mount: Mortise
Gauge: 0.122″ (Thickness of Hinge Brass)
Knuckles: 5
Screw holes: 6
Material: Solid Brass
Emtek is dedicated to bringing interesting, well made hardware back into American homes. Emtek’s mission is to satisfy the higher expectations of today’s homeowners with regard to door locks. They strive to provide a broad and interesting range of products that consumers can use as elements of decor, and not just as a way to latch a door.
Additional Emtek Links
View the Manufacturer Warranty
Browse all Emtek Products
Emtek 3-1/2 Inch Hinges Collection
Characteristics and Features
| Material | Brass |
| Thermostat | Traditional |
| Hinge Type | Ball Bearing |
| Hole Pattern | Arc |
| Mounting Type | Mortise |
| Number Of Hooks | 6 |
| Number of Knuckles | 5 |
| Removable Pin | Yes |
| Sconce Type | Wood |
Warranty and Product Information
| Approved for Commercial Use | No |
| Collection | Brass Modern, Classic Brass, Designer Brass |
| Series | 3-1/2 Inch Hinges |
| Usage Level | Heavy Duty |
Dimensions and Measurements
| Quantity | 2 |
| Gauge | 0.122 |
| Corners | Square Corner |
| Hinge Height | 3.5 in. |
| Hinge Size | 3-1/2 x 3-1/2 in. |
| Hinge Width | 3.5 in. |
| Color | Flat Black, French Antique, Lifetime Polished Brass, Oil Rubbed Bronze, Pewter, Polished Chrome, Polished Nickel, Satin Brass, Satin Nickel, Unlacquered Brass |
| Color Tone | Blacks, Brass Tones, Bronze Tones, Neutrals, Nickel Tones, Silver Tones |
