Bring resort-level ambiance to your outdoor living space with the American Fyre Designs Phoenix Vent-Free Outdoor Fireplace. Handcrafted from durable glass fiber reinforced concrete (GFRC), the vent-free Phoenix is blocked at the top and throat and is certified to be installed under a covered area — ideal for covered patios, pergolas, and outdoor rooms where a vented chimney is not practical.
- Handcrafted glass fiber reinforced concrete (GFRC) construction withstands harsh climates
- Vent-free design is certified to go under a covered area (blocked at the top and the throat)
- Includes four herringbone firebox liners for a finished masonry look
- Choice of 16-inch radiused bullnose or dramatic 113-inch extended bullnose hearth
- Optional 2-inch recess on hearth and/or body accommodates field cladding in tile, stone, or veneer
- Compatible with vent-free log sets or glass media with G10/G21 vent-free burner systems (sold separately)
Configuration Guide
- Required: choose your finish color, hearth style, and recess option. The gas shut-off key valve is located on the right side with the gas source out the back.
- Recess options (optional): No Recess, Hearth Only, or Hearth and Body — a 2″ deep recess on all vertical sides for cladding in stone, tile, or brick.
- Sold separately (required to operate): a vent-free burner system and media — G10 vent-free stainless steel log burner (up to 24″/30″ with 24″ log) or G21 vent-free contemporary glass/gems burner (up to 24″), in natural gas or propane, plus your choice of vent-free log set or glass media.
Specifications
| Model | 117-xx-x-xx-RBC |
| Dimensions | 65″W x 36″D x 87″H |
| Weight | 1,100 lbs |
| Pieces | 7 |
| Construction | Glass Fiber Reinforced Concrete (GFRC) |
| Fuel | Natural Gas or Propane (burner sold separately) |
| Type | Vent-Free Outdoor Fireplace |
| Certification | ANSI Z21.97-2017 / CSA 2.41 outdoor decorative gas appliance |
| Warranty | 3-year GFRC body / 1-year components |
What’s Included
- Phoenix vent-free fireplace structure in your selected finish, hearth style, and recess configuration
- Four herringbone firebox liners
- Crated freight shipment
Documentation
- Installation & Owner’s Manual
- Spec Sheet
Please Note: American Fyre Designs products are for outdoor use only. Each piece is individually handcrafted and made to order, so orders cannot be canceled once placed. Finishes are subject to slight texture and color variation; samples are available upon request.
Warranty: American Fyre Designs covers the GFRC fireplace body with a 3-year limited warranty; burners, valves, and electronic components carry a 1-year limited warranty.
